| Protection degree: |
IP67 according to EN 60529 and IP69K according to ISO 20653 |
| Housing: |
Metal housing, three threaded M20x1,5 conduit entries |
| Head: |
Rotating head |
| Working method: |
D working method, locked actuator with de-energized solenoid |
| Inputs And Outputs: |
2 safety inputs IS1-IS2,2 safety outputs OS1-OS2,1 signalling output O3 actuator inserted,1 signalling output O4 actuator locked,I4 or IE1-IE2 inputs for solenoid activation,1 input I3 actuator programming / reset |
| Safety Output Activation OS: |
Activation mode 1 safety outputs active with actuator inserted and locked |
| Actuator: |
Without actuator |
| Type of Connection: |
Without connector |
| Cover configuration: |
No device |
