Idem 174401: HLM-CBA 2NC 2NO with Plastic Roller M20 | Safety Switch Accessories
“Compact, die-cast belt alignment switch with 70mm roller, 22mm diameter.”
| Attribute | Value |
|---|---|
| Approvals: | cULus |
| Technology: | Mini Belt Alignment Switch |
| Housing Material: | Painted Die-Cast Metal |
| UL Info: | Type 1 Enclosures. Use 16 – 12AWG copper conductors, rated 75ºC minimum. Intended for same polarity use. Electrical Rating A300 240V.ac 3A. (6,000 cycles) 240V. 10A. carry only. Wire range 16AWG – 12AWG Copper Torque 7lb/in (0.8Nm) Earth bonding terminal inside enclosure if required. |
| Roller Material: | 316 Grade Stainless Steel or Polyester |
| Thermal Current (Ith): | 10A |
| Enclosure Protection: | IP67 |
| Operating Temperature: | -25 … +80 °C |
| Vibration: | IEC 68-2-6, 10-55Hz 0.35mm |
| Fixing: | M5 Bolts (Torque 2.0Nm) |
| Utilization Category: | AC15 A300 240V. 3A |
| Min Current: | 5V, 5mA, DC |
| Rated Impulse Withstand Volt: | 2500VAC |
| Mechanical Life Expectancy: | 500,000 Cycles |
| Typical operating parameters: | 0.4Nm Torque 15-30 degrees contact changeover |
| Conductor Size: | 1.5 sq.mm |
| Product Number | Variant Description |
|---|---|
| 174451 | HLM-CBA 2NC 2NO with SS Roller M20 |
| 174453 | HLM-CBA 2NC 2NO with SS Roller QC-M23 |
| 174403 | HLM-CBA 2NC 2NO with Plastic Roller QC-M23 |
| 174452 | HLM-CBA 2NC 2NO with SS Roller 1/2″NPT |
| 174402 | HLM-CBA 2NC 2NO with Plastic Roller 1/2″NPT |
