| Rated insulation voltage Ui: |
75 V |
| Rated impulse voltage Uimp: |
0.5 kV |
| Degree of protection: |
IP65(In the closed state when the connection cables, connecting cables and submodules are correctly mounted; assembly.) |
| Item designation: |
MGB2-L2-MLI-M-Y0000-BJ-158711 |
| Gross weight: |
1,19kg |
| ECLASS: |
27-27-24-05 Safety-related transponder switch with guardlocking |
| EMC protection requirements: |
EMC Directive 2014/30/EU |
| Safety Class: |
III |
| Current consumption: |
max. 350 mA |
| Degree of contamination (external, according to EN 60947-1): |
3 |
| Switching frequency: |
0.25 Hz |
| Shock And Vibration Resistance: |
Acc. to EN IEC 60947-5-3 |
| Transponder coding: |
Multicode |
| Locking force FZh: |
2000 N |
| Guard locking principle: |
Open-circuit current principle |
| Response time: |
See operating instructions for bus module MBM-… |
| Slotkonfiguration: |
1,1 |
