Euchner 122722E | MSC-CE-SPM2TB-122722 : Proximity Switches

The MSC-CE-SPM2TB-122722 is a versatile proximity switch that provides accurate object detection, ideal for improving efficiency in automated systems.

Request a quote

    Attribute Value
    Connection Cross Section: 0.5 … 2.5 mm²(Screw terminal)
    Rated insulation voltage Ui: 250 V
    Connection Type: RJ45
    Degree of protection: IP20
    Ambient temperature: -10 … +55 °C
    Item designation: MSC-CE-SPM2TB-122722
    Gross weight: 0,241kg
    ECLASS: 27-24-22-05 SPS-Funktions-/Technologie-Modul
    Rated surge voltage according to IEC 60664-1: 4000 V
    Degree of contamination according to EN 60664-1: 2
    Mounting type: TH 35 mounting rail (EN IEC 60715)
    Overvoltage category according to IEC EN 60664-1: II
    Performance Level: PL e(according to ISO 13849-12008 / EN 620612005)
    Category: 4(according to ISO 13849-12008 / EN 620612005)
    PFHD: 1.12E-08 1/h(according to IEC 615082010)
    Mission time: 20 y(according to ISO 13849-12008 / EN 620612005)
    Atmospheric humidity: 10 … 95 % rH
    Dimensions: 108 x 22.5 x 114.5(Including screw terminals)
    Cable length: max. 100 m
    Input Type: PNP / NPN 3/4-wires
    Power Dissipation: max. 3 W
    Storage temperature: -20 … +85 °C
    Spacing limits: min. 5 %
    Number: 1
    Frequency: max. 500 kHz
    Frequency spacing: min. 10 Hz
    Limit range: 1Hz – 450kHz(parameterizable)
    Number of axes: 2
    Product Number Variant Description
    MSC-CE-SPM2TB-122722 : Proximity Switches (No others)
