Euchner 120403E | MGB-A-PLUGCONNECTOR-RC18-120403 : Mgb-Zubehoer (112333) Bis V1.2.3
The MGB-A-PLUGCONNECTOR-RC18-120403 is a connector designed for Mgb-Zubehoer systems, ensuring reliable connectivity.
| Attribute | Value |
|---|---|
| Connection Type: | Male plug |
| Degree of protection: | IP65(locked) |
| Item designation: | MGB-A-PLUGCONNECTOR-RC18-120403 |
| Gross weight: | 0,085kg |
| Cable Outlet: | straight |
| Number of pins: | 19 |
| Plug lock: | Screw connection |
| Tightening torque: | 1.5 Nm |
| Conductor Identification: | Color code |
| Conductor Cross-section: | 16x 0.5 mm² + 2x 0.75 mm² |
| Conductor End: | Cable end sleeve with insulating collar |
| Plug connector designation: | RC(With shield spring) |
| Product Number | Variant Description |
|---|---|
| MGB-A-PLUGCONNECTOR-RC18-120403 : Mgb-Zubehoer (112333) Bis V1.2.3 | (No others) |
