Euchner 116420E | CET4-AS-CRA-AB-50F-1-C2333-116420 : Cet-Asi

The Cet-Asi is an advanced control unit that enhances the functionality of industrial equipment with its intuitive design.

Request a quote

    Attribute Value
    Approach speed: max. 20 m/min
    Installation Orientation: any
    Mechanical Life: 2 x 10?
    Degree of protection: IP67(When inserted and secured)
    Item designation: CET4-AS-CRA-AB-50X-SJ-AS1-113631
    Gross weight: 1,134kg
    ECLASS: 27-27-24-05 Safety-related transponder switch with guardlocking
    Safety Class: III
    Degree of contamination (external, according to EN 60947-1): 3
    Switching frequency: max. 0.5 Hz
    Shock And Vibration Resistance: Acc. to EN IEC 60947-5-3
    Notices For UL Approval: Operation only with UL Class 2 power supply or equivalent measures; see operating instructions
    Locking force FZh: 5000 N(FZH = FMAX/1.3)
    Guard locking principle: Open-circuit current principle
    Mission time: 20 y
    Locking force Fmax: 6500 N
    Degree of freedom X: ±5 mm
    Degree of freedom Y: ±5 mm
    Degree of freedom Z: ±4 mm
    ASI operating current: max. 50 mA
    AS-Interface auxiliary voltage: 24 V -15 … 10 %
    Auxiliary current AS-Interface: 480 mA
    AS-Interface protocol: ASi-3
    ASI data out: D0 = control of guard locking, D1 = red LED, D2 = green LED
    ASI data in: D0, D1 = door position, D2, D3 = guard locking
    AS-Interface slave type: ID-Code B, EA-Code 7
    ASI voltage: 22.5 … 30 … 31.6 V
    Product Number Variant Description
    CET4-AS-CRA-AB-50F-1-C2333-116420 : Cet-Asi (No others)
