Euchner 110872E | MGB-L1-ARA-AD4A1-S1-R-110872 : Multifunctional Gate Box Locking M.

The Multifunctional Gate Box Locking M provides secure locking mechanisms for gate systems, enhancing safety and functionality.

Request a quote

    Attribute Value
    Rated insulation voltage Ui: 30 V
    Rated impulse voltage Uimp: 1.5 kV
    Switching current: 1 … 10 mA
    Connection Type: Plug connector RC18(X6)
    Installation Orientation: Door hinge DIN right
    Degree of protection: IP65
    Item designation: MGB-L1-ARA-AD4A1-S1-R-110872
    Gross weight: 1,084kg
    ECLASS: 27-27-24-05 Safety-related transponder switch with guardlocking
    Risk time according to EN 60947-5-3: max. 350 ms
    Risk time according to EN 60947-5-3, extension for each additional device: max. 5 ms
    Safety Class: III
    Degree of contamination (external, according to EN 60947-1): 3
    Output Type: Semiconductor outputs, p-switching, short circuit-proof
    Test Pulse Duration: max. 1 ms
    Test Pulse Interval: min. 100 ms
    Switching frequency: 0.25 Hz
    Switching voltage: UAV
    Product version number: V4.0.0
    Occupancy diagram: L1
    Transponder coding: Unicode
    Breaking capacity: max. 0.25 W
    LED Power Supply: 24 V DC
    Locking force FZh: 2000 N
    Guard locking principle: Closed-circuit current principle
    Product Number Variant Description
    MGB-L1-ARA-AD4A1-S1-R-110872 : Multifunctional Gate Box Locking M. MGB-L1-ARA-AD4A1-S1-L-110873 : Multifunctional Gate Box Locking M.
