| Connection Type: |
Female plug |
| Degree of protection: |
IP67/IP69K(in the screwed tight state) |
| Item designation: |
C-M08F08-08X014PU10,0-ES-106672 |
| Gross weight: |
0,321kg |
| ECLASS: |
27-06-03-04 Appliance cord (data cable) |
| Rated voltage: |
30 V |
| Degree of contamination according to EN 60664-1: |
3 |
| Cable Outlet: |
straight |
| Number of pins: |
8 |
| Plug lock: |
Screw connection |
| Tightening torque: |
0.3 Nm |
| Dynamic bending radius: |
10 x cable diameter |
| Static bending radius: |
5 x cable diameter |
| Cable ambient temperature (dynamic): |
-25 … +80 °C |
| Cable ambient temperature (static): |
-40 … +80 °C |
| Cable length: |
10 m |
| Specific Capacitance: |
102 nF/km |
| Conductor Identification: |
Color code |
| Conductor Cross-section: |
0.14 mm² |
| Number of conductors: |
8 |
| Fire Behavior: |
flame retardant according to IEC 60332-2, UL FT-2 |
| Cable Type: |
straight |
| Drag chain suitability: |
yes |
| Conductor End: |
Cable end sleeve |
| Halogen-free: |
yes |
