Euchner 104833E | ZXE-104833 : Enabling Pushbutton

The ZXE-104833 enabling pushbutton is designed for safety applications, ensuring that machinery operates only when intended.

Request a quote

    Attribute Value
    Rated insulation voltage Ui: 30 V
    Rated impulse voltage Uimp: 1.5 kV
    Switching current: 5 … 100 mA
    Connection Type: Screw terminal, 4-pin
    Number of switching elements: 2 Normally open contact
    Actuating force: max. 50 N(from stage 2 to 3)
    Installation Orientation: any
    Ambient temperature: -5 … +60 °C
    B10D: 0.75 x 10?
    Item designation: ZXE-104833
    Gross weight: 0,053kg
    ECLASS: 27-37-12-38 Agreement switch
    Degree of contamination (external, according to EN 60947-1): 3
    Rated Conditional Short-circuit Current: 100 A
    Additional feature: Click
    Breaking capacity: max. 0.25 W
    Stripping length: 5 mm
    in compliance with: DIN EN 60947-5-8
    Rated actuating force according to EN 60947-5-8: 100
    Product Number Variant Description
    ZXE-104833 : Enabling Pushbutton (No others)
