Euchner 100742E | CMS-R-AXE-SC : Read Head
The CMS-R-AXE-SC read head offers reliable performance and accuracy, making it ideal for industrial automation systems.
Request a quote
Attribute | Value |
---|---|
Rated insulation voltage Ui: | 26.4 V |
Rated impulse voltage Uimp: | 1.5 kV |
Switching current: | 8 … 500 mA |
Connection Type: | 4-pin M8 plug connector |
Number of NO contacts: | 3 NO contacts |
Design: | A |
Installation Orientation: | any |
Mechanical Life: | 100 x 10? |
Degree of protection: | IP67 |
Ambient temperature: | -20 … +60 °C |
Item designation: | CMS-R-AXE-SC |
Gross weight: | 0,058kg |
ECLASS: | 27-27-24-02 Safety-related magnetic proximity switch |
Repeat Accuracy R: | max. 10 % |
Tightening torque: | 0.4 … 0.5 Nm |
Shock And Vibration Resistance: | Acc. to EN IEC 60947-5-3 |
Secured Switch-off Distance Sar: | max. 34 mm(The assured release distance s_ar corresponds to the reset distance.) |
Method of Operation: | magnetic, reed contact |
Switching characteristics: | parallel |
in compliance with: | EN ISO 13849-12015; EN 501781997; EN 60204-12006/A12009; EN ISO 141192013; EN 61000-6-22005; EN 61000-6-32007/A12011; EN 60947-5-32013 |
Product Number | Variant Description |
---|---|
CMS-R-AXE-SC : Read Head | (No others) |
