| Rated insulation voltage Ui: |
60 V |
| Rated impulse voltage Uimp: |
2 kV |
| Short circuit protection according to IEC 60269-1: |
4A gG |
| thermal rated current Ith: |
4 A |
| Approach speed: |
0.01 … 20 m/min |
| Connection Type: |
1 x plug connector RC18(Coninvers RC18, 19-pin (18+PE). Not adjustable. Cable outlet for angle plug connector to the rear.) |
| Number NC contacts: |
4 |
| Number of switching elements: |
4 |
| Number of NO contacts: |
4 |
| Design: |
upright, according to DIN 43697 |
| Actuating element: |
Chisel plunger |
| Actuating force: |
min. 20 N |
| Installation Orientation: |
any |
| Mechanical Life: |
30 x 10? |
| Contact bounce time: |
max. 3 ms |
| Switching principle: |
Snap-action switching contact |
| Operating point accuracy: |
± 0,002(The reproducible operating point accuracy refers to the axial travel of the plunger after the switching element ES 502 E has been run-in with approx. 2,000 operating cycles.) |
| Schließzeit: |
max. 4 ms |
| Degree of protection: |
IP65(only screwed tight with the related mating connector.) |
| Plunger spacing: |
12 mm |
| Ambient temperature: |
-5 … +70 °C |
| Additional information: |
Exterior diaphragm = AM(The exterior diaphragm provides additional protection for the plunger guide. Plunger sticking, primarily caused by resinous lubricating coolants, can be prevented by this AM version.) |
| Item designation: |
RGBF04D12-502AMLE024GE-MC2177 |
| Gross weight: |
0,957kg |
| ECLASS: |
27-27-06-02 Multi-position switch |
