Euchner 099512E | ES550/2 : Snap Switch

The ES550/2 Snap Switch offers a compact design for easy installation and dependable performance in controlling electrical circuits.

Request a quote

    Attribute Value
    Rated insulation voltage Ui: 250 V
    Rated impulse voltage Uimp: 1.5 kV
    Short circuit protection according to IEC 60269-1: 4A gG
    thermal rated current Ith: 4 A
    Approach speed: 0.01 … 50 m/min
    Actuating force: 15 … 20 N
    Installation Orientation: any
    Mechanical Life: 10 x 10?
    Switching principle: Changeover contact with snap-action function
    Degree of protection: IP67
    Ambient temperature: -5 … +80 °C
    Item designation: N01R550SEM5-M
    Gross weight: 0,096kg
    ECLASS: 27-27-06-01 Position switch (Type 1)
    Number of door position NO contacts: 1(Changeover contact)
    Number of door position NC contacts: 1 Changeover contact
    Product Number Variant Description
    ES550/2 : Snap Switch (No others)
