Euchner 097525E | CES-A-W5H-01 : Evaluation Unit

The CES-A-W5H-01 Evaluation Unit is designed for testing and evaluating various electronic components and systems.

Request a quote

    Attribute Value
    Rated insulation voltage Ui: 75 V(Tested by the employersÂ’ liability insurance association up to 75 V.)
    Rated impulse voltage Uimp: 1.5 kV
    Connection Type: M12 plug connector, 8-pin; shield can be connected
    Installation Orientation: any
    Degree of protection: IP65/IP67
    Item designation: CES-A-W5H-01
    Gross weight: 0,349kg
    ECLASS: 27-27-24-03 Safety-related transponder switch
    Operating voltage DC: 18 … 24 … 27 V DC regulated, residual ripple<5%
    EMC protection requirements: Acc. to EN IEC 60947-5-3
    Current consumption: 80 mA
    Degree of contamination (external, according to EN 60947-1): 3
    Output Type: Semiconductor outputs, p-switching, short circuit-proof, electrically decoupled(To ensure safety, both safety outputs (LA and LB) must be evaluated.)
    Rated Conditional Short-circuit Current: max. 100 A
    Ready Delay: max. 3 s(After the operating voltage is switched on, the semiconductor outputs are switched off and the monitoring outputs are set to LOW level during the ready delay.)
    Switching frequency: max. 1 Hz
    Notices For UL Approval: Operation only with UL Class 2 power supply or equivalent measures
    Secured Switch-off Distance Sar: max. 58 mm
    Switching hysteresis: 1 … 2 mm(for non-flush mounting; assembly on aluminum)
    Dwell time: min. 0.5 s(The dwell time of an actuator inside and outside the actuating range must be at least 0.5 s to ensure safe detection of internal faults in the evaluation unit (self-monitoring).)
    Dimensions: according to EN 60947-5-2 (LxWxH) 131x40x40
    Product Number Variant Description
    CES-A-W5H-01 : Evaluation Unit (No others)
