Euchner 097368E | CMS-R-BZB-03V : Read Head
The CMS-R-BZB-03V is a compact read head designed for high-precision data acquisition and control applications.
Request a quote
Attribute | Value |
---|---|
Switching current: | max. 100 mA |
Connection Type: | Hard-wired encapsulated cable with cable end sleeves 0.34 mm2 |
Number of NO contacts: | 2 NO contacts with internal fuse, 100 mA each |
Design: | B |
Installation Orientation: | any |
Mechanical Life: | 100 x 10? |
Degree of protection: | IP67 |
Ambient temperature: | -20 … +60 °C |
B10D: | 20 x 10? |
Item designation: | CMS-R-BZB-03V |
Gross weight: | 0,185kg |
ECLASS: | 27-27-24-02 Safety-related magnetic proximity switch |
Rated Conditional Short-circuit Current: | 100 A(Parameter dependent on the evaluation units ESM-BA2.. and ESM-BA3..) |
Tightening torque: | 0.4 … 0.5 Nm |
Secured Switch-off Distance Sar: | max. 20 mm(The assured release distance s_ar corresponds to the reset distance.) |
Switching voltage: | 24 … 35 V(DC) |
Cable length: | 3 m |
Method of Operation: | magnetic, reed contact |
Switching characteristics: | parallel |
in compliance with: | EN ISO 13849-1 2015; EN 62061 2005 + AC 2010 + A1 2013 + A2 2015; EN ISO 14119 2013; IEC 60947-5-3 2013 |
Switching delay from state change: | max. 26 ms(Parameter dependent on the evaluation units ESM-BA2.. and ESM-BA3..) |
Product Number | Variant Description |
---|---|
CMS-R-BZB-03V : Read Head | CMS-R-BZB-05P : Read Head |
