| Material: |
Polycarbonate |
| Connection Type: |
Plug connector(19-pin, metal version) |
| Ambient temperature: |
0 … +50 °C |
| Item designation: |
HBAS-094594 |
| Gross weight: |
1,206kg |
| ECLASS: |
27-33-02-02 Mobile Panel (HMI) |
| Operating voltage DC: |
24 V DC -20% … +20% |
| Current consumption: |
max. 100 mA(without switched-on LEDs) |
| Shock And Vibration Resistance: |
according to EN 60068-2-27/-2-6 |
| Notices For UL Approval: |
Operation only with UL Class 2 power supply or equivalent measures |
| Connecting cable: |
23×0.14 mm² |
| Date Interface: |
RS422 |
| Data Protocol: |
3964R, 8 data bits, even parity |
| Data Rate: |
9.6 … 19.2 kbit/s(automatic adjustment during initialization) |
