Euchner 092355E | NZ2VZ-2131E-8C-GMMF : Safety Switch
$701.11
Explore the Euchner 092355E | NZ2VZ-2131E-8C-GMMF : Safety Switch. Now sold at Venus Automation. Request a quote now!
| Attribute | Value |
|---|---|
| Product Code: | 092355E |
| Installation Orientation: | any |
| Storage temperature: | -25 … 80 °C |
| Degree of protection: | IP65 |
| Ambient temperature: | -25 … 80 °C |
| Order Number: | 092355 |
| Item designation: | NZ2VZ-2131E-8C-GMMF |
| Gross weight: | 0,397kg |
| Customs tariff number: | 85365019000 |
| ECLASS: | 27-27-26-02 Safety switch with separate actuator (Type 2) |
| Mechanical Life: | 2 x 10? |
| Rated insulation voltage Ui: | 250 V |
| Rated impulse voltage Uimp: | 2.5 kV |
| Fuse: | max. 4 A gG |
| Connection Cross Section: | 0.34 … 1.5 mm² |
| Switching voltage: | 12 V |
| thermal rated current Ith: | 4 A |
| Approach Speed: | max. 20 m/min |
| Number of door position positively driven contacts: | 3 |
| Extraction Force: | 35 N |
| Actuation frequency: | max. 1200 1/h |
| Actuating force: | 35 N |
| Insertion Depth: | 52 mm |
| Retention Force: | 8 N |
| Switching principle: | Slow-action switching contact |
| Overtravel: | 16 mm |
| Approach direction: | A |
| Number of door position NO contacts: | 1 |
