Euchner 091296E | SR11AM2-M20 : Connector
The SR11AM2-M20 is a robust connector ideal for ensuring secure electrical connections in industrial settings.
| Attribute | Value |
|---|---|
| Connection Cross Section: | 0.14 … 0.5 mm² |
| Connection Type: | Male plug |
| Degree of protection: | IP65 |
| Ambient temperature: | -40 … +90 °C |
| Item designation: | SR11AM2-M20 |
| Gross weight: | 0,018kg |
| Cable Outlet: | straight |
| Number of pins: | 12 11 + PE |
| Plug lock: | Screw connection |
| Plug connector designation: | SR11 |
| Rated Current I: | 5000 mA |
| Product Number | Variant Description |
|---|---|
| SR11AM2-M20 : Connector | SR11AM2-M20X : Connector |
