Euchner 088883E | RPS3131SC175M : Rope Pull Switch
The RPS3131SC175M is a durable rope pull switch designed for emergency stop applications, providing a reliable means of control in various industrial settings.
| Attribute | Value |
|---|---|
| Connection Cross Section: | 0.08 … 1.5 mm² |
| Rated insulation voltage Ui: | 250 V |
| Rated impulse voltage Uimp: | 2.5 kV |
| Short circuit protection according to IEC 60269-1: | 6A gG |
| thermal rated current Ith: | 10 A |
| Number of NO contacts: | 2 |
| Number of positively driven contacts: | 2 |
| Actuating force: | 175 N |
| Installation Orientation: | any |
| Mechanical Life: | 0.1 x 10? |
| Switching principle: | Slow-action switching contact |
| Degree of protection: | IP67 |
| Ambient temperature: | -25 … +70 °C |
| Item designation: | RPS3131SC175M |
| Gross weight: | 0,75kg |
| ECLASS: | 27-37-12-01 Emergency stop pull cord switch |
| Safety Class: | II |
| Additional feature: | Emergency stop function |
| Rope diameter: | 2 … 5 mm |
