Euchner 087245E | N1AB508-M : Single Plunger

The N1AB508-M is a robust single plunger switch, suitable for a range of industrial applications requiring dependable performance.

Request a quote

    Attribute Value
    Connection Cross Section: 0.34 … 1.5 mm²
    Rated insulation voltage Ui: 250 V
    Rated impulse voltage Uimp: 4 kV
    Short circuit protection according to IEC 60269-1: 10A gG
    thermal rated current Ith: 10 A
    Approach speed: 0.01 … 120 m/min
    Number of switching elements: 1
    Number of positively driven contacts: 1
    Design: Housing according to DIN 43693
    Actuating element: Roller plunger(Ball bearings)
    Actuating force: min. 15 N
    Installation Orientation: any
    Mechanical Life: 30 x 10?
    Switching principle: Slow-action switching contact
    Degree of protection: IP67
    Ambient temperature: -25 … +80 °C
    B10D: 20 x 10?
    Item designation: N1AB508-M
    Gross weight: 0,233kg
    ECLASS: 27-27-06-01 Position switch (Type 1)
    Roller diameter: 8 mm
    Product Number Variant Description
    N1AB508-M : Single Plunger (No others)
