| Connection Cross Section: |
0.34 … 1.5 mm² |
| Rated insulation voltage Ui: |
60 V |
| Design: |
Housing according to DIN 43693 |
| Installation Orientation: |
any |
| Switching principle: |
NO + NC |
| Degree of protection: |
IP67 |
| Ambient temperature: |
-25 … +70 °C |
| Item designation: |
ENA10B050UP048LKK10-M |
| Gross weight: |
0,252kg |
| ECLASS: |
27-27-01-01 Inductive proximity switch |
| Operating voltage DC: |
10 … 55 V DC |
| EMC protection requirements: |
IEC 60947-5-2 |
| Output Type: |
PNP |
| Off-state Current Ir: |
max. 0.001 mA |
| Switching frequency: |
max. 500 Hz |
| Switching hysteresis: |
max. 0.5 mm |
| Reverse Polarity Protection: |
yes |
| LED Display: |
no |
| Rated operating distances Sn: |
5 mm |
| Assured operating distances Sa: |
0 … 4 mm(Dimension applies only to steel (ST37) and to EUCHNER trip dogs of series UX.. / GX..) |
| Rated operating current Ie: |
max. 250 mA |
| Short Circuit And Overload Protection, Pulsed: |
yes |
| No-load Current I0: |
15 |
| Voltage drop Ud: |
max. 2.5 V |
