| Rated insulation voltage Ui: |
26.4 V |
| Rated impulse voltage Uimp: |
1.5 kV |
| Switching current: |
8 … 500 mA |
| Connection Type: |
Hard-wired encapsulated cable with cable end sleeves 0.34 mm2 |
| Number NC contacts: |
1 NC contact |
| Number of NO contacts: |
1 NO contacts |
| Design: |
C |
| Installation Orientation: |
any |
| Mechanical Life: |
100 x 10? |
| Degree of protection: |
IP67 |
| Ambient temperature: |
-20 … +60 °C |
| Item designation: |
CMS-R-CXC-05V |
| Gross weight: |
0,295kg |
| ECLASS: |
27-27-24-02 Safety-related magnetic proximity switch |
| Repeat Accuracy R: |
max. 10 % |
| Tightening torque: |
0.4 … 0.5 Nm |
| Shock And Vibration Resistance: |
Acc. to EN IEC 60947-5-3 |
| Secured Switch-off Distance Sar: |
max. 14 mm(The assured release distance s_ar corresponds to the reset distance.) |
| Switching voltage: |
24 V |
| Cable length: |
5 m |
| Method of Operation: |
magnetic, reed contact |
| Switching characteristics: |
NO + NC |
| in compliance with: |
EN ISO 13849-12015; EN 501781997; EN 60204-12006/A12009; EN ISO 141192013; EN 61000-6-22005; EN 61000-6-32007/A12011; EN 60947-5-32013 |
