Euchner 085253E | SN01R553-M : Single Plunger

The SN01R553-M Single Plunger is engineered for optimal performance in actuation tasks, ensuring high reliability and responsiveness.

Request a quote

    Attribute Value
    Connection Cross Section: 0.14 … 1 mm²
    Rated insulation voltage Ui: 250 V
    Rated impulse voltage Uimp: 2.5 kV
    Short circuit protection according to IEC 60269-1: 6A gG
    thermal rated current Ith: 6 A
    Approach speed: 0.01 … 50 m/min
    Actuating force: 15 … 20 N
    Installation Orientation: any
    Mechanical Life: 10 x 10?
    Switching principle: Changeover contact with snap-action function
    Degree of protection: IP67
    Ambient temperature: -5 … +80 °C
    Item designation: SN01R553-M
    Gross weight: 0,109kg
    ECLASS: 27-27-06-01 Position switch (Type 1)
    Number of door position NO contacts: 1(Changeover contact)
    Number of door position NC contacts: 1 Changeover contact
    Product Number Variant Description
    SN01R553-M : Single Plunger (No others)
