Euchner 084576E | CMS-R-CXB-03V : Read Head
The CMS-R-CXB-03V is a reliable read head that ensures precise tracking and measurement in various automation systems.
Request a quote
Attribute | Value |
---|---|
Rated insulation voltage Ui: | 26.4 V |
Rated impulse voltage Uimp: | 1.5 kV |
Switching current: | 8 … 500 mA |
Connection Type: | Hard-wired encapsulated cable with cable end sleeves 0.75 mm2 |
Number of NO contacts: | 3 NO contacts |
Design: | C |
Installation Orientation: | any |
Mechanical Life: | 100 x 10? |
Degree of protection: | IP67 |
Ambient temperature: | -20 … +60 °C |
Item designation: | CMS-R-CXB-03V |
Gross weight: | 0,186kg |
ECLASS: | 27-27-24-02 Safety-related magnetic proximity switch |
Repeat Accuracy R: | max. 10 % |
Degree of contamination (external, according to EN 60947-1): | 2 |
Tightening torque: | 0.4 … 0.5 Nm |
Shock And Vibration Resistance: | Acc. to EN IEC 60947-5-3 |
Secured Switch-off Distance Sar: | max. 16 mm(The assured release distance s_ar corresponds to the reset distance.) |
Cable length: | 3 m |
Method of Operation: | magnetic, reed contact |
Switching characteristics: | in series |
in compliance with: | EN ISO 13849-12015; EN 501781997; EN 60204-12006/A12009; EN ISO 141192013; EN 61000-6-22005; EN 61000-6-32007/A12011; EN 60947-5-32013 |
Product Number | Variant Description |
---|---|
CMS-R-CXB-03V : Read Head | CMS-R-CXB-05V : Read Head |
