Euchner 072604E | SCHLUESSELSCHALTER : Key Operated Switch
The SCHLUESSELSCHALTER is a key operated switch designed for secure control of electrical devices.
Request a quote
Attribute | Value |
---|---|
Switching current: | max. 5 mA |
Connection Type: | Soldered connection |
Number of switching elements: | 2 1 NO contact, 1 NC contact |
Mechanical Life: | 2 x 10? |
Switching principle: | Snap-action switching element |
Degree of protection: | IP65(when installed) |
Ambient temperature: | -25 … +55 °C |
Item designation: | SCHLUESSELSCHALTER RUND |
Gross weight: | 0,028kg |
Contact Resistance: | max. 50 m? New value |
Color: | black |
Switching characteristics: | Latching function |
Product Number | Variant Description |
---|---|
SCHLUESSELSCHALTER : Key Operated Switch | SCHLUESSELSCHALTER ABZUGST 0/1 : Key Operated Switch |
SCHLUESSELSCHALTER : Key Operated Switch | SCHLUESSELSCHALTER RUND : Key Operated Switch |
