| Rated insulation voltage Ui: |
250 V |
| Rated impulse voltage Uimp: |
2.5 kV |
| Short circuit protection according to IEC 60269-1: |
4A gG |
| Connection Type: |
Tab connector 2.8 x 0.8 IEC 760 |
| Number of NO contacts: |
2 |
| Number of positively driven contacts: |
1 |
| Installation Orientation: |
any |
| Switching principle: |
Slow-action contact element |
| Ambient temperature: |
-5 … +60 °C |
| B10D: |
0.5 x 10? |
| Item designation: |
ZSE2-2C1692 |
| Gross weight: |
0,11kg |
| ECLASS: |
27-37-12-38 Agreement switch |
| Degree of contamination (external, according to EN 60947-1): |
3 |
| Rated Conditional Short-circuit Current: |
100 A |
| in compliance with: |
60947-5-8 |
