Euchner 041758E | FRONTPLATTE M KPL. : Frontplate
The FRONTPLATTE M KPL. is a durable front plate designed to provide protection and aesthetic appeal to your devices.
Request a quote
Attribute | Value |
---|---|
Material: | Aluminum |
Connection Cross Section: | 0.08 … 2.5 mm² |
Connection Type: | Screw terminal, 6-pin |
Ambient temperature: | 0 … +70 °C |
Item designation: | HKD025S100G12 |
Gross weight: | 0,404kg |
ECLASS: | 27-24-23-07 Command-, control-, signal appliance |
Operating voltage DC: | 10 … 30 V DC |
Output Type: | Push-pull |
Tightening torque: | max. 0.5 Nm |
Shock And Vibration Resistance: | according to EN 60068-2-27/-2-6 |
Detent mechanism: | Magnetic |
Connection cross section AWG: | 28 … 12 AWG |
Pulses Per Revolution: | 2×25 |
Detent Positions Per Revolution: | 100 |
Product Number | Variant Description |
---|---|
FRONTPLATTE M KPL. : Frontplate | FRONTPLATTE F KPL. : Frontplate |
FRONTPLATTE M KPL. : Frontplate | FRONTPLATTE G KPL. : Frontplate |
FRONTPLATTE M KPL. : Frontplate | FRONTPLATTE K KPL. : Frontplate |
FRONTPLATTE M KPL. : Frontplate | FRONTPLATTE S KPL. : Frontplate |
FRONTPLATTE M KPL. : Frontplate | FRONTPLATTE HBM : Frontplate |
FRONTPLATTE M KPL. : Frontplate | FRONTPLATTE HBM : Frontplate |
FRONTPLATTE M KPL. : Frontplate | FRONTPLATTE HBM : Front Plate |
FRONTPLATTE M KPL. : Frontplate | FRONTPLATTE HBM : Frontplate |
