| Rated insulation voltage Ui: |
250 V |
| Rated impulse voltage Uimp: |
2.5 kV |
| Short circuit protection according to IEC 60269-1: |
T10/F20 |
| Connection Type: |
Screw terminal |
| Mechanical Life: |
1 x 10? |
| Switching principle: |
Changeover contact C, IEC 947-5-1(Snap-action contact element, design ES517A) |
| Ambient temperature: |
-25 … +65 °C |
| Item designation: |
KFT1234 |
| Gross weight: |
0,186kg |
| ECLASS: |
27-37-14-04 Control switch, joystick |
| Switching voltage: |
min. 12 V |
| Number of monitoring contacts: |
4(4 directions) |
| Actuating directions: |
4(Pushbutton) |
| Mounting cut-out: |
D22 (EN IEC 60947-5-1) |
