Dold Module BH5928.92/61 AC/DC24V 0,03-0,3S 65565
DOLD BH5928.92/61 AC/DC24V 0,03-0,3S – Efficient, reliable electrical solution.
Request a quote
Attribute | Value |
---|---|
Width: | 45 mm |
Nominal voltage: | DC, AC/DC |
Thermal current Ith max.: | 050000 |
Connection: | Pluggable screw terminals |
Output contacts max.: | 3 NO contacts, 3 NO contacts delayed |
Type: | BH 5928 |
Approvals: | UL |
Cat. / PL Acc. To EN ISO 13849-1: | 4/e |
SIL Acc. To IEC/EN 62061: | 3 |
1- / 2-channel: | 1, 2 |
Cross Fault Detection: | Yes |
Suited as safety gate monitor: | Yes |
Product Number | Variant Description |
---|---|
50077 | BH5928.92/61 AC/DC24V 0,1-1S |
49448 | BH5928.92/61 AC/DC24V 0,3-3S |
50715 | BH5928.92/61 AC/DC24V 0,5-5S |
52498 | BH5928.92/61 DC24V 6-60S |
49447 | BH5928.92/61 DC24V 30-300S |
56924 | BH5928.92/61 DC24V 3-30S |
53982 | BH5928.92/61 AC/DC24V 6-60S |
49445 | BH5928.92/61 DC24V 0,3-3S |
60264 | BH5928.92/61 DC24V 0,5-5S |
49446 | BH5928.92/61 DC24V 1-10S |
61174 | BH5928.92/61 DC24V 0,1-1S |
49450 | BH5928.92/61 AC/DC24V 30-300S |
50653 | BH5928.92/61 AC/DC24V 3-30S |
49449 | BH5928.92/61 AC/DC24V 1-10S |
