DOLD 0053477: BL5903.22/00000 AC110V Emergency stop module with voltage failure detection
For plants, that should start automatically at return of voltage after phase failure. E.g. Compressor plants, water and sewage water plants.
| Attribute | Value |
|---|---|
| Width: | 90 mm |
| Type: | BL 5903 |
| Cat. / PL Acc. To EN ISO 13849-1: | 4/e |
| SIL Acc. To IEC/EN 62061: | 3 |
| Output contacts max.: | 3 NO contacts |
| Nominal voltage: | AC |
| Thermal current Ith max.: | 5 A |
| 1- / 2-channel: | 1, 2 |
| Connection: | Pluggable screw terminals |
| Cross Fault Detection: | Yes |
