DOLD 0041408: CA3056.05 AC/DC24V Interface relay
The interface relays CA 3056, CB 3056 and CC 3056 are used for contact multiplication and are suitable as a link between the control and power level. The interface relays are available with different contact combinations and partly for switching small loads.
| Attribute | Value |
|---|---|
| Width: | 11,5 mm |
| Enclosure design: | Switch cabinet |
| Type: | CA 3056 |
| Output contacts max.: | 1 NO contact, 1 NC contact |
| Nominal voltage: | AC, AC/DC |
| Thermal current Ith max.: | 5 A |
| Suppressor Circuit On the Coil Input: | Yes |
| Initiator triggering: | Yes |
