| Model |
pin insert |
| Inflammability Class of Insulation Material Acc. with UL94 |
V0 |
| Color |
grey |
| Mating Cycles |
200 |
| Pollution Degree |
3 |
| Suitable For Modular Version |
no |
| Operating Temperature Range Min. |
-40°C |
| Operating Temperature Range Max. |
120°C |
| Connection Type |
crimp |
| Number of Poles |
48 |
| Plus Switching Contacts |
0 |
| Number of Pole For Rated Current 2 |
0 |
| Number of Pole For Rated Current 3 |
0 |
| Total Number of Poles (without Ground Contact) |
48 |
| With Wire Protection |
no |
| Protective Contact |
yes |
| Nominal Voltage According To UL/CSA |
600V |
| Nominal Current According UL |
16A |
| Nominal Current According CSA |
16A |
| Min. Conductor Cross Section Flexible Wire |
0.5mm² |
| Max. Conductor Cross Section Flexible Wire |
4mm² |
| Conductor Cross Section Flexible AWG Wire |
20-12 AWG |
| With Housing |
no |
| Contact Material |
see contacts |
| Surface |
see contacts |
| Contact Resistance |
?1.5mOhm |
| Wire Strip Length |
7mm |
| Mounting Screws |
H1/0.5-0.7 Nm |
| Ground Conductor Screws |
H2/1.2-1.6 Nm |
| Nominal Voltage |
500V |
| Nominal Voltage Face/ground |
500V |
| Nominal Current |
16A |
| Rated Impulse Voltage |
6kV |
| ECLASS 8.1 |
27440205 |
| ETIM 9.0 |
EC000438 |
| ETIM 8.0 |
EC000438 |
| ETIM 7.0 |
EC000438 |
| ETIM 6.0 |
EC000438 |
| ETIM 5.0 |
EC000438 |
| ETIM 4.0 |
EC000438 |
| ETIM 3.0 |
EC000438 |
| ROHS Conformity Status |
compliant |
| REACH-SVHC Conformity Status |
compliant |
