Mechan Magnasafe Series
Description
The Mechan-Magnasafe-Series is a compact, magnetically operated safety switches designed for use with modern safety relays. The MS5SS safety switches are easy to install, tolerant to misalignment. The MS5SSHT are equipped with a special cable for use in high temperature environments, e.g. cooking / food processing. The MS5SSLQD version has 150mm connecting cable with M12, 6 pole connector, and can be supplied with 5 or 10 metre matching cable. The non-contact operation of the Mechan-Magnasafe-Series has a 7 – 10 mm switching distance helping to ensure a long and trouble free operating life.
Specifications
Compliance
Downloads
| Part Number | Safety Output | Safety Output Rating | Cable Length | Dimensions of Switch (mm) | Operating Temperature |
| MS5SS (Non contact safety switches) | UP TO 2 X NO | 24VDC / 300MA | 3, 6 OR 10 Metre | 53 X 29 X 13.5 | -10°C TO 55°C |
| MS5SSHT (Used for High Temperature Environment) | UP TO 2 X NO | 24VDC / 300MA | 5 OR 10 Metre | 53 X 29 X 13.5 | -25°C TO +125°C |
| MS5SSLQD (M12, 6 pole connector) | UP TO 2 X NO | 24VDC / 300MA | 150 Millimetre | 53 X 29 X 13.5 | -25°C TO +55°C |
