HTL Output Encoders
Description
The SENC series of Safe HTL Incremental Output Encoders provides safe monitoring of motors, drives or shafts for rotational speed, rotational direction or position monitoring applications to IEC 61800-5-2 standards. Usage applications include safe direction detection for rolls, gates or machines, safely reduced speed for setup mode or jog mode, and safely limited position for rotational or linear axes as well as shutdown monitoring for commissioning or maintenance. These models are compatible with the given accessories listed below and are designed for integration with the Wieland Samos pro COMPACT PLUS control module.
Specifications
Compliance
Downloads
| Model | Order Number | Shaft Type | Diameter | Supply Voltage | Resolution | Connector | Protection and Safety Rating |
|---|---|---|---|---|---|---|---|
| SENC-58S10HTL0360A | R1.450.1010.0 | Solid Shaft | 10mm | 24VDC | 360ppr | Radial M23 – 12 Pin connector | IP65 SIL 3 – SILCL 3 PL e – Cat. 4 |
| SENC-58S10HTL0360R | R1.450.1020.0 | Solid Shaft | 10mm | 24VDC | 360ppr | Radial M23 – 12 Pin connector | IP65 SIL 3 – SILCL 3 PL e – Cat. 4 |
| SENC-58S10HTL0512A | R1.450.1030.0 | Solid Shaft | 10mm | 24VDC | 512ppr | Radial M23 – 12 Pin connector | IP65 SIL 3 – SILCL 3 PL e – Cat. 4 |
| SENC-58S10HTL0512R | R1.450.1040.0 | Solid Shaft | 10mm | 24VDC | 512ppr | Radial M23 – 12 Pin connector | IP65 SIL 3 – SILCL 3 PL e – Cat. 4 |
| SENC-58S10HTL1024A | R1.450.1050.0 | Solid Shaft | 10mm | 24VDC | 1024ppr | Radial M23 – 12 Pin connector | IP65 SIL 3 – SILCL 3 PL e – Cat. 4 |
| SENC-58S10HTL1024R | R1.450.1060.0 | Solid Shaft | 10mm | 24VDC | 1024ppr | Radial M23 – 12 Pin connector | IP65 SIL 3 – SILCL 3 PL e – Cat. 4 |
| SENC-58H14HTL0360R | R1.450.1110.0 | Hollow Shaft | 14mm | 24VDC | 360ppr | Radial M23 – 12 Pin connector | IP65 SIL 3 – SILCL 3 PL e – Cat. 4 |
| SENC-58H14HTL0512R | R1.450.1120.0 | Hollow Shaft | 14mm | 24VDC | 512ppr | Radial M23 – 12 Pin connector | IP65 SIL 3 – SILCL 3 PL e – Cat. 4 |
| SENC-58H14HTL1024R | R1.450.1130.0 | Hollow Shaft | 14mm | 24VDC | 1024ppr | Radial M23 – 12 Pin connector | IP65 SIL 3 – SILCL 3 PL e – Cat. 4 |
| SENC-90S11HTL1024A | R1.450.1250.0 | Solid Shaft | 11mm (12mm on request) | 24VDC | 1024ppr (360 or 512 ppr on request) | Radial M23 – 12 Pin connector | IP65 SIL 3 – SILCL 3 PL e – Cat. 4 |
| SENC-90S11HTL1024R | R1.450.1260.0 | Solid Shaft | 11mm (12mm on request) | 24VDC | 1024ppr (360 or 512 ppr on request) | Radial M23 – 12 Pin connector | IP65 SIL 3 – SILCL 3 PL e – Cat. 4 |
| SENC-90H30HTL1024R | R1.450.1330.0 | Hollow Shaft | 30mm (reduction via reducing bushes possible) | 24VDC | 1024ppr (360 or 512 ppr on request) | Radial M23 – 12 Pin connector | IP65 SIL 3 – SILCL 3 PL e – Cat. 4 |
ACCESSORIES: Encoder Cable
| Model | Order Number | Description |
|---|---|---|
| CABLE-M23CKW-PUR-015 | R1.450.9310.0 | Encoder Cable, 1.5m, PUR, Shielded |
| CABLE-M23CKW-PUR-030 | R1.450.9314.0 | Encoder Cable, 3m, PUR, Shielded |
| CABLE-M23CKW-PUR-050 | R1.450.9320.0 | Encoder Cable, 5m, PUR, Shielded |
| CABLE-M23CKW-PUR-070 | R1.450.9324.0 | Encoder Cable, 7m, PUR, Shielded |
| CABLE-M23CKW-PUR-100 | R1.450.9330.0 | Encoder Cable, 10m, PUR, Shielded |
| CABLE-M23CKW-PUR-150 | R1.450.9335.0 | Encoder Cable, 15m, PUR, Shielded |
| CABLE-M23CKW-PUR-200 | R1.450.9340.0 | Encoder Cable, 20m, PUR, Shielded |
ACCESSORIES: Shaft
| Model | Order Number | Description |
|---|---|---|
| COUP-SHAFT-58S-S-10-10 | R1.450.9250 | Shaft coupling, solid, shaft, size 58mm, shaft diameter 10mm to 10mm |
| KEY-SHAFT-58S-S-04-10 | R1.450.9260 | Shaft key, solid shaft, size 58mm, width 4mm, length 10mm |
ACCESSORIES: Flange Adapters
| Model | Order Number | Description |
|---|---|---|
| FLANGE-58-A | R1.450.9210 | Flange adapter, size 58mm, aluminium |
| FLANGE-90-A | R1.450.9220 | Flange adapter, size 90mm, aluminium |
ACCESSORIES: Coupling
| Model | Order Number | Description |
|---|---|---|
| COUP-STATOR-58-S | R1.450.9110.0 | Stator Coupling, size 58mm, stainless-steel |
| COUP-TETHER-58-S | R1.450.9120.0 | Tether arm coupling, size 58mm, stainless-steel |
| COUP-STATOR-90-S | R1.450.9130.0 | Stator Coupling, size 90mm, stainless-steel |
| COUP-TETHER-90-S | R1.450.9140.0 | Tether arm coupling, size 90mm, stainless-steel |
ACCESSORIES: Reduction Sleeves
| Model | Order Number | Description |
|---|---|---|
| SLEEVE-90H-P-30-20 | R1.450.9040 | Reduction sleeve, hollow shaft, size 90mm, 30mm shaft diameter to 20mm |
| SLEEVE-90H-P-30-21 | R1.450.9050 | Reduction sleeve, hollow shaft, size 90mm, 30mm shaft diameter to 21mm |
| SLEEVE-90H-P-30-22 | R1.450.9060 | Reduction sleeve, hollow shaft, size 90mm, 30mm shaft diameter to 22mm |
| SLEEVE-90H-P-30-23 | R1.450.9070 | Reduction sleeve, hollow shaft, size 90mm, 30mm shaft diameter to 23mm |
| SLEEVE-90H-P-30-24 | R1.450.9080 | Reduction sleeve, hollow shaft, size 90mm, 30mm shaft diameter to 24mm |
| SLEEVE-90H-P-30-25 | R1.450.9090 | Reduction sleeve, hollow shaft, size 90mm, 30mm shaft diameter to 25mm |
